A sparse MPC solver for walking motion generation (old version).: Problem definition

Model of the system

3D linear inverted pendulum is used as an approximate model of a humanoid robot.

$\tilde{\mbm{c}}_{k+1} = \tilde{\mbm{A}}_k\tilde{\mbm{c}}_{k}+\tilde{\mbm{B}}_k\dddot{\mbm{c}}_{k}, \quad \dddot{\mbm{c}}_{k} = (\dddot{c}_k^x, \dddot{c}_k^y)$

$\mbm{A} = \left[\hspace{-0.1cm} \begin{array}{cccccc} 1 & T_k & T_k^{2}/2 & 0 & 0 & 0 \vspace{0.05cm}\\ 0 & 1 & T_k & 0 & 0 & 0 \vspace{0.05cm}\\ 0 & 0 & 1 & 0 & 0 & 0 \vspace{0.05cm}\\ 0 & 0 & 0 & 1 & T_k & T_k^{2}/2 \vspace{0.05cm}\\ 0 & 0 & 0 & 0 & 1 & T_k \vspace{0.05cm}\\ 0 & 0 & 0 & 0 & 0 & 1 \end{array} \hspace{-0.1cm}\right], \quad \mbm{B}_k = \left[\hspace{-0.1cm} \begin{array}{cc} T_k^{3}/6 & 0 \vspace{0.05cm} \\ T_k^{2}/2 & 0 \vspace{0.05cm} \\ T_k & 0\\ 0 & T_k^{3}/6 \vspace{0.05cm} \\ 0 & T_k^{2}/2 \vspace{0.05cm} \\ 0 & T_k \end{array} \right]$

Where $T_k$ is a time sampling period in the preview window.

Originally the state vector is defined as $\hat{\mbm{c}}_{k} = (c_k^x,\dot{c}_k^x,\ddot{c}_k^x,c_k^y,\dot{c}_k^y,\ddot{c}_k^y)$ where $c^x_k, c^y_k$ are coordintes of the center of mass.

Variable substitutions

The first substitution

After the first variable substitution we get $\tilde{\mbm{c}}_{k} = (z_k^x,\dot{c}_k^x,\ddot{c}_k^x,z_k^y,\dot{c}_k^y,\ddot{c}_k^y)$ where $z^x_k, z^y_k$ are coordintes of the ZMP.

The state and control input matrices are changed accordingly:

$\tilde{\mbm{A}} = \left[ \begin{array}{cccccc} 1 & T_k & T_k^{2}/2-\Delta h_k & 0 & 0 & 0 \vspace{0.05cm}\\ 0 & 1 & T_k & 0 & 0 & 0 \vspace{0.05cm}\\ 0 & 0 & 1 & 0 & 0 & 0 \vspace{0.05cm}\\ 0 & 0 & 0 & 1 & T_k & T_k^{2}/2-\Delta h_k \vspace{0.05cm}\\ 0 & 0 & 0 & 0 & 1 & T_k \vspace{0.05cm}\\ 0 & 0 & 0 & 0 & 0 & 1 \end{array} \right], \quad \tilde{\mbm{B}} = \left[ \begin{array}{cc} T^{3}/6-hT & 0 \\ T^{2}/2 & 0\\ T & 0\\ 0 & T^{3}/6-hT \\ 0 & T^{2}/2\\ 0 & T \end{array} \right]$

Here $h = c_k^z/g$ , i.e. the height of center of mass divided by the norm of gravitational acceleration;

The second substitution

The last substitution rotates the state vector using matrix

$\bar{\mbm{R}}_k = \left[ \begin{array}{cccccc} \cos\theta_k & 0 & 0 & -\sin\theta_k & 0 & 0 \\ 0 & 1 & 0 & 0 & 0 & 0 \\ 0 & 0 & 1 & 0 & 0 & 0 \\ \sin\theta_k & 0 & 0 & \cos\theta_k & 0 & 0 \\ 0 & 0 & 0 & 0 & 1 & 0 \\ 0 & 0 & 0 & 0 & 0 & 1 \end{array} \right].$

where $\theta_k$ is an angle with respect to the world frame.

$\bar{\mbm{c}}_{k} = \bar{\mbm{R}}_k^T \tilde{\mbm{c}}_{k} = (\bar{z}_k^x,\dot{c}_k^x,\ddot{c}_k^x,\bar{z}_k^y,\dot{c}_k^y,\ddot{c}_k^y)$

Objective function

Output matrices for position and velocity:

$\mbm{C}_p = \left[ \begin{array}{cccccc} 1 & 0 & 0 & 0 & 0 & 0 \\ 0 & 0 & 0 & 1 & 0 & 0 \\ \end{array}\right], \quad \mbm{C}_v = \left[ \begin{array}{cccccc} 0 & 1 & 0 & 0 & 0 & 0 \\ 0 & 0 & 0 & 0 & 1 & 0 \\ \end{array}\right],$

$\bar{f}(\bar{\mbm{v}}) = \left[\hspace{-0.1cm}\begin{array}{c} \bar{\mbm{v}}_c \\ \mbm{v}_u \end{array}\hspace{-0.1cm}\right]^T \left[\hspace{-0.1cm}\begin{array}{cc} \tilde{\mbm{H}}_c & \mbm{0} \\ \mbm{0} & \mbm{H}_u \end{array}\hspace{-0.1cm}\hspace{-0.1cm}\right] \left[\hspace{-0.1cm}\begin{array}{c} \bar{\mbm{v}}_c \\ \mbm{v}_u \end{array}\hspace{-0.1cm}\right] + \left[\hspace{-0.1cm}\begin{array}{c} \bar{\mbm{v}}_c \\ \mbm{v}_u \end{array}\hspace{-0.1cm}\right]^T \left[\hspace{-0.1cm}\begin{array}{c} \bar{\mbm{g}}_c \\ \mbm{0} \end{array}\hspace{-0.1cm}\right]$

where

$\bar{\mbm{v}}_c$ is a column vector containing state vectors and $\bar{\mbm{v}}_u$ is a column vector containing control inputs.

$f(\mbm{v}) = \frac{\gamma}{2}\sum_{k=0}^{N-1}\left(\dddot{\mbm{c}}_k^T\dddot{\mbm{c}}_k\right) + \frac{\alpha}{2}\sum_{k=1}^{N}\left(\dot{\mbm{c}}_k^T\dot{\mbm{c}}_k\right) + \frac{\beta}{2}\sum_{k=1}^{N}\left(\mbm{z}_k^T\mbm{z}_k - 2\mbm{z}_k^T\mbm{z}^{\mbox{ref}}_k\right),$

where $\alpha, \beta, \gamma > 0$ are gains.

$\frac{\beta}{2}\mbm{z}_k^T\mbm{z}_k - \beta\mbm{z}_k^T\mbm{z}^{\mbox{ref}}_k = \bar{\mbm{c}}_k^T\frac{\beta}{2}\mbm{C}_p^T\mbm{C}_p\bar{\mbm{c}}_k - \bar{\mbm{c}}_k^T\underbrace{\bar{\mbm{R}}^T_k\beta\mbm{C}_p^T\mbm{z}^{\mbox{ref}}_k}_{\bar{\mbm{q}}_k}, \\ \bar{\mbm{v}}_c = \left[\begin{array}{c} \bar{\mbm{c}}_1 \\ \vdots \\ \bar{\mbm{c}}_N \end{array} \right], \quad \bar{\mbm{g}}_c = \left[\begin{array}{c} -\bar{\mbm{q}}_1 \\ \vdots \\ -\bar{\mbm{q}}_N \end{array} \right], \quad \bar{\mbm{v}} = \left[\begin{array}{c} \bar{\mbm{v}}_c \\ \mbm{v}_u \end{array} \right]$

$\\ \mbm{H}_u = \left[ \begin{array}{ccc} \mbm{P} & \dots & \mbm{0} \\ \vdots & \ddots & \vdots \\ \mbm{0} & \dots & \mbm{P} \\ \end{array} \right],\quad \mbm{P} = \left[ \begin{array}{cc} \frac{\gamma}{2} & 0 \\ 0 & \frac{\gamma}{2} \\ \end{array} \right];\\ \tilde{\mbm{H}}_c = \left[ \begin{array}{ccc} \tilde{\mbm{Q}} & \dots & \mbm{0} \\ \vdots & \ddots & \vdots \\ \mbm{0} & \dots & \tilde{\mbm{Q}} \\ \end{array} \right], \quad \tilde{\mbm{Q}} = \left[ \begin{array}{cccccc} \frac{\beta}{2} & 0 & 0 & 0 & 0 & 0\\ 0 & \frac{\alpha}{2} & 0 & 0 & 0 & 0\\ 0 & 0 & r & 0 & 0 & 0\\ 0 & 0 & 0 & \frac{\beta}{2} & 0 & 0 \\ 0 & 0 & 0 & 0 & \frac{\alpha}{2} & 0 \\ 0 & 0 & 0 & 0 & 0 & r \\ \end{array} \right]$

Here $r$ is a regularization factor, which makes the matrix nonsingular.

Equality constraints

$\bar{\mbm{E}}_c\bar{\mbm{v}}_c + \tilde{\mbm{E}}_u\mbm{v}_u = \bar{\mbm{e}},$

where $\bar{\mbm{e}} = (-\mbm{A}\bar{\mbm{R}}_0\bar{\mbm{c}}_0, \mbm{0}, \dots, \mbm{0})$ ,

$\bar{\mbm{E}}_c = \left[ \begin{array}{cccccc} -\bar{\mbm{R}}_1 & \mbm{0} & \mbm{0} & \dots & \mbm{0} & \mbm{0} \\ \mbm{A}\bar{\mbm{R}}_1 & -\bar{\mbm{R}}_2 & \mbm{0} & \dots & \mbm{0} & \mbm{0} \\ \mbm{0} & \mbm{A}\bar{\mbm{R}}_2 & -\bar{\mbm{R}}_3 & \dots & \mbm{0} & \mbm{0} \\ \vdots & \vdots & \vdots & \ddots & \vdots & \vdots \\ \mbm{0} & \mbm{0} & \mbm{0} & \dots & \mbm{A}\bar{\mbm{R}}_{N-1} & -\bar{\mbm{R}}_N \\ \end{array} \right], \quad \tilde{\mbm{E}}_u = \left[ \begin{array}{cccc} \tilde{\mbm{B}} & \dots & \mbm{0} \\ \vdots & \ddots & \vdots \\ \mbm{0} & \dots & \tilde{\mbm{B}} \\ \end{array} \right].$

See page 'Derivation of the matrix of equality constraints' for example.

Inequality constraints

$\left[ \begin{array}{cccccc} -1 & 0 & 0 & 0 & 0 & 0 \\ 0 & 0 & 0 & -1 & 0 & 0 \\ 1 & 0 & 0 & 0 & 0 & 0 \\ 0 & 0 & 0 & 1 & 0 & 0 \end{array} \right]\bar{\mbm{c}}_k + \mbm{d}_{k} \geq \mbm{0},$
